Carbon Monoxide Monitor Model: TSP-CO Series

สินค้า

Carbon Monoxide Monitor Model: TSP-CO Series

ชื่อสินค้า : Carbon Monoxide Monitor Model: TSP-CO Series

รหัส : Model: TSP-CO Series

แบรนด์ : Tongdy

ไฟล์เอกสาร :

Download

รายละเอียด :

FEATURES

Real-time monitoring Carbon Monoxide concentration in the air, With optional temperature detection
Industrial class structure design for housings, firm and durable
Inside famous Japanese Carbon Monoxide sensor with up to 5 years lifetime
Modbus RTU or BACnet -MS/TP communication optional
OLED display optional
Three-color LED indicates different CO level
Buzzer alarm for setpoint
Different CO ranges selectable
Sensor coverage up to 30 meters radius subject to air movement.
1x 0-10V or 4-20mA analog linear output for CO measured value
Provide up to two on/off relay outputs
24VAC/VDC power supply

TECHNICAL SPECIFICATIONS

Power Supply	24VAC/VDC
Power Consumption	2.8W
Connection Standard	Wire cross-sectional area<1.5mm2
Operating Environment	-5-50℃（0-50℃ for TSP-DXXX）, 0~95%RH
Storage Environment	-5-60℃/ 0~95%RH,non-condensing
Dimension/Net Weight	95mm(W)117mm(L)36mm(H) / 280g
Manufacturing Standard	ISO 9001
Housings and IP class	PC/ABS fire-proof material; IP30 protection class
Design Standard	CE-EMC Approval
Sensor
CO Sensor	Japanese Electrochemical CO Sensor
Sensor Lifetime	Up to 3~5 years and replaceable
Warm Up Time	60 minutes(First use),1 minute(daily use)
Response Time(T90)
Signal Refreshing	One second
CO Range (Optional)	0-100ppm(Default)/0-200ppm/0-300ppm/0-500ppm
Accuracy	<±1 ppm + 5% of reading (20℃/ 30~60%RH)
Stability	±5% (over 900 days)
Temperature Sensor(Optional	Capacitive sensor
Measuring Range	-5℃-50℃
Accuracy	±0.5℃ (20~40℃)
Display Resolution	0.1℃
Stability	±0.1℃/year

FEATURES

TECHNICAL SPECIFICATIONS
